Modeling Method of Stress Concentrated Members for First Order Analysis

Abstract

This paper proposes a modeling method of stress-concentrated members for the first; der analysis(FOA). When a complicated solid structure is simplified as an assemblage of simple beam elements applied to elements forces such as axial force, shear force, bending moment, and twisting moment, the total stiffness equation for FOA of the solid structure is constructed and solved for the given boundary and loading conditions by the usual FEM manner. Then, the total deformation of the simple model is estimated and the element forces are calculated at the element level, The stress concentration of simplified each member with holes, notches, and variable cross-section is also predicted by the suggested approximate formulation, A U-notched3D-model is picked up and how precisely the suggested formulas can predict the stress concentration will be shown. These formulas can be used to show the influence of the design parameter changes to the designer and how the load transmission path will change by the design changes
